02 · Emergency StopFunction
Emergency stop — lanyard / pull cord
Trip modes
Pull, over-tension, cord removal
Reset
Manual reset knob
Emergency Stop Pull Cord Device
Safe-T-Pull
Tested to AS4024, AS/NZS 3947.5.5 and IEC 60947.5.5.
The Safe-T-Pull lanyard device is designed to initiate a positive tripping mechanism when certain conditions are met. Positive tripping can occur manually via the reset knob or automatically when one or both trip cords are removed, over-tensioned, or activated. This is a crucial safety feature to halt conveyor systems in emergency situations.
The Safe-T-Pull lanyard device has been tested to meet the requirements of Australian Standard AS4024 (Safety of Machinery), AS/NZS 3947.5.5 and IEC 60947.5.5 — demonstrating that the device has been designed and tested to meet industry safety standards.
Installed according to the specific installation instructions, the Safe-T-Pull will ensure compliance with the relevant Australian and international standards.
Key features
- Positive trip on pull, over-tension or cord removal
- Manual reset knob
- Tension and non-tension variants
- Raised device option — STP(R) — with 3 m adjustable cord
- Direct replacement for common competitor lanyard devices
Specification
- Function
- Emergency stop — lanyard / pull cord
- Trip modes
- Pull, over-tension, cord removal
- Reset
- Manual reset knob
- Ingress protection
- IP66 / IP67
- Cord
- Vectran™ or 316 stainless, PU coated
- Standards
- AS4024, AS/NZS 3947.5.5, IEC 60947.5.5
Enclosure materials
- High impact PC/PBT — UV stable, flame retardant
- 3mm powder coated aluminium
- 2mm 316 electro-polished stainless steel
Ordering codes
Representative codes. Full configuration — contacts, hand, arms, terminations — is confirmed on quotation against the technical document.
- STP-PPC/PBT plastic pull cord device
- STP(R)Raised device, 3 m adjustable cord
- STP-20-SS8mm 316 hook/eye turnbuckle
- STP-90-SS10 × 180mm pig tail, 304 stainless
- STP-ES-SSTent shaped reflective emergency stop sign
